To use the KLG4 manifold you will need a KLG4 Throttlebody (or aftermarket that requires modifications)
The G4 manifold uses a different style TPS that has only 3 wires and connects to the throttle butterfly diffrerently.  It also has different style IAC but still uses the same 2 wires.
KLDE vs KLG4 TPS comparison
Buying the TPS Sensor
Finding the KLG4 TPS to buy can be a bit challenging because there are verisons that look similar but are not the same. Also finding the connector for the TPS based on a search for KLG4 or 2002 626 can be almost impossible or very expensive.
However this TPS is used on other vehicles and you can even find the TPS with a connector for a very cheap cost. Shown below is an example.
Other vehicles the TPS can be found for:
2000-2004 Suzuki Aerio,Swift, Verona, Esteem
1998-2001 Chevy Metro
1998-2000 Pontiac Firefly
Part # TPS4112 13420-52G00
OE # 13420-52G00, S2088
Other: 5S5063, 158-0613, 1580613, TH244,1342052G00, 1985001130, 91173884 1985001130
Wiring the KLG4 TPS for KLDE Engine ECM
Wiring the KLG4 TPS to your KLDE wiring is straight forward. Transfer the wires pointing to the pins with green wires to the corresponding position shown.
 You will not use the IDLE switch wire.
